Found 3 results

  1. GalvanicGlaze

    Version 1.0.0

    855 downloads

    I've made some alternative beacon mounts for myself that i'll share I wasn't happy with the original mount because as soon as the carriage got a bit melted the probe would start touching the heat block (see attached photo). I also believe because the probe is so close to the heater it causes the mount the deform. I've made a mount that sits the probe back 2mm from the original but I have not tested this one, this brings me the other other mount I made. The second mount is specific to a Dragon hotend that is rotated 180°. I did this to be able to see the nozzle better and it's now possible as there is no more probe in the way of achieving this. So far it's working well for me I've printed my parts out of PCCF so if anyone can report their findings with an ABS mount that would be great but moving the probe should have done the trick. The original beacon mount from annex can be found here if you were looking for that: https://github.com/Annex-Engineering/Annex-Engineering_User_Mods/tree/main/Printers/Non_Annex_Printers/VORON_Printers/VORON_V2dot4/annex_dev-stealthburner_beacon_x_carriage
  2. GalvanicGlaze

    Version 1.0.0

    792 downloads

    I've made a mount for the Beacon3D probe for a CW2 Switchwire I used the normal version beacon probe Mount has been tested and works great, here is a youtube short of it in action *** I've added a second mount as that moved the probe 2mm further away I wasn't happy with the original mount because as soon as the carriage got a bit melted the probe would start touching the heat block. I also believe because the probe is so close to the heater it causes the mount the deform.
  3. waffles

    Version 1.0.0

    35 downloads

    Made a drop in mount for anyone still using CW1. Not sure if it'll work with the CW2. Requires the low profile beacon. The normal version will not work with this mount. QTY: 2 - Brass heat insert from 2.4 BOM My Beacon config [beacon] serial: [insert your address here] x_offset: 0 # update with offset from nozzle on your machine y_offset: 22.5 # update with offset from nozzle on your machine backlash_comp: [change to whatever yours is] mesh_main_direction: x mesh_runs: 2
×
×
