   Voron 0.2

   The official release of the Voron Zero 3D printer. You can find the BOM in the configurator located at the Voron Design website.
   The current revision is V0.2
   Printed Parts Guide
   Highlights
   Compact and portable 120x120x120 build volume CoreXY Low mass direct drive extruder Enclosed chamber 24v DC bed Klipper firmware Release History
   V0.2 (2023 January)
   A majority of the printed parts have changed. The configurator will give you an idea of parts needed if you are upgrading from V0.1.
   Toolhead
   New design: Mini Stealth Burner Direct Drive Extruder with BMG gears and 20mm thick pancake motor with 10 tooth spur gear Improved part cooling ducts (fans are same as V0.1) Supports Revo VORON, Dragon, Dragonfly BMO, DropEffect XG, Creality Spider Pro Drive units
   Motor screw count reduction Endstop removed for sensorless homing Frame
   No changes Tophat
   All panels have changed All side panels are identical Extrusion based Tophat Hinged design Cam locks to secure tophat in place Panels/Clips
   All Panels are 3mm Deck panel changed, new panel is not required Split rear panel X/Y Joints
   Tops became 1mm smaller to accommodate MiniSB Endstop block removed for sensorless homing Bed Assembly
   Printed parts changed, bed position moved 3mm to the rear Feet/Skirts
   Trident skirt community mod folded into offical release Front Idlers
   Cam Locks added V0.1 Inital release (2021 April)
   See https://github.com/VoronDesign/Voron-0/releases/tag/V0.1
   V0.0 Updates and fixes (2020 Sept)
   See https://github.com/VoronDesign/Voron-0/releases/tag/V0.0r1
   V0.0 Initial release (2020 April)
   See https://github.com/VoronDesign/Voron-0/releases/tag/V0.0
