2.4 Wiring Gallery

iNDeX · October 5, 2021


Hi,

where can I find the STL for the WAGO Connectors?

Demosth · October 5, 2021

https://www.teamfdm.com/search/?&tags=wago&search_and_or=or

michaelmacintyre · December 17, 2021

These images make me droop my head in shame.

I look at these and think they seem to have a 10th of the amount of wires i do but they must just be better at hiding them.

Demosth · December 17, 2021

@michaelmacintyre - i HEAR you.

I try to add more as I find them across the internet, so i can continue to feel worse about myself. Many of those configurations are artists in their own right!

You are welcome to contribute to the album as well - I want this gallery to become more of a resource for people looking for great wiring ideas.

michaelmacintyre · December 17, 2021

I have one in my browser that ive been keeping in the hope to get mine as clean as the guy has got his.

I will upload it. I'm printing some rails and things for underneath to try and tidy mine up.

My problem is I hate cutting the wires in case I want to use the part in another printer later. I know its stupid because I can always just extend the wires again if I need to do that.
